<table id="spec_table"><tbody><tr><td colspan="2">SYSTEM</td></tr><tr><td>MB FORM FACTOR</td><td>Mini-ITX</td></tr><tr><td>CPU</td><td>Intel&reg; LGA1700 12/13/14th Gen Socket Processor (Formerly Alder Lake-S, TDP 65W)</td></tr><tr><td>CHIPSET</td><td>Intel&reg; Q670E</td></tr><tr><td>MEMORY</td><td>2 x DDR5 4800MT/s SO-DIMM, up to 96GB<br />2 x DDR5 5600MT/s SO-DIMM, up to 64GB (Intel&reg; 13th/14th Gen CPU)</td></tr><tr><td>BIOS</td><td>AMI 256Mb Flash ROM</td></tr><tr><td>WATCHDOG TIMER</td><td>255 Levels</td></tr><tr><td>SECURITY</td><td>TPM2.0</td></tr><tr><td>DIMENSION (W X D)</td><td>170.0 (W) x 170.0 (D) mm (6.7&Prime; x 6.7&Prime;)</td></tr><tr><td>OS SUPPORT</td><td>Windows&reg; 11 (64bit)<br />Windows&reg; 10 (64bit)<br />Linux</td></tr><tr><td colspan="2">POWER</td></tr><tr><td>POWER REQUIREMENT</td><td>ATX Power Supply</td></tr><tr><td>POWER ON MODE</td><td>AT / ATX</td></tr><tr><td>CONNECTOR</td><td>24+4-pin ATX PWR</td></tr><tr><td colspan="2">DISPLAY</td></tr><tr><td>GPU</td><td>Intel&reg; UHD Graphics</td></tr><tr><td>LVDS</td><td>1 x 24-bit Dual Channel LVDS (Max. Resolution: 1920 x 1200 @60Hz, Co-lay eDP)</td></tr><tr><td>DP</td><td>1 x DP 1.4a (Max Resolution: 8K@60Hz)</td></tr><tr><td>HDMI&reg;</td><td>1 x HDMI&reg; 2.0b (Max Resolution: 4096 x 2160@60Hz)</td></tr><tr><td>VGA</td><td>1 x VGA (Max Resolution: 1920 x 1080 @60Hz)</td></tr><tr><td>MULTIPLE DISPLAY</td><td>Support 4 Displays</td></tr><tr><td colspan="2">AUDIO</td></tr><tr><td>CODEC</td><td>Realtek Audio Codec</td></tr><tr><td>Line-in</td><td>1 x Audio Jack for Line-In</td></tr><tr><td>Line-out</td><td>1 x Audio Jack for Line-Out</td></tr><tr><td>MIC-in</td><td>1 x Audio Jack for MIC-In</td></tr><tr><td colspan="2">LAN</td></tr><tr><td>ETHERNET</td><td>1 x RJ45 for Intel&reg; I226-V 2.5GbE<br />1 x RJ45 for Intel&reg; I219-LM GbE</td></tr><tr><td colspan="2">USB PORT</td></tr><tr><td>USB</td><td>6 x USB 3.2 Gen 2<br />Internal Header for 2 x USB 3.2<br />Internal Header for 3 x USB 2.0</td></tr><tr><td colspan="2">SERIAL PORT</td></tr><tr><td>COM</td><td>1 x DB-9 for RS-232/422/485<br />1 x DB-9 for RS-232<br />Internal Header for 4 x RS-232</td></tr><tr><td colspan="2">INTERNAL I/O</td></tr><tr><td>GPIO</td><td>8-Bit</td></tr><tr><td>SMBUS</td><td>Yes</td></tr><tr><td>ADDITIONAL</td><td>1 x Chassis Intrusion<br />1 x Audio Header<br />1 x PS/2<br />1 x LVDS (co-layout eDP)</td></tr><tr><td colspan="2">STORAGE</td></tr><tr><td>SATA</td><td>4 x SATA III</td></tr><tr><td>RAID</td><td>RAID 0, 1, 5, 10</td></tr><tr><td colspan="2">EXPANSION</td></tr><tr><td>M.2</td><td>1 x M-Key 2280 (PCIe Gen.3 x4 interface) support NVMe<br />1 x M-Key 2242 (PCIe Gen.4 x4/SATA interface) support NVMe<br />1 x E-Key 2230 (USB 2.0/PCIe 3.0 x1) Support CNVi<br />1 x B-key 3042 (PCIe Gen.3 x1/USB3.2 Gen.2/USB2.0 interface) support 4G Module</td></tr><tr><td>PCIe</td><td>1 x PCIe x16 (Gen.4)</td></tr><tr><td>SIM</td><td>1 x SIM Card Slot</td></tr><tr><td colspan="2">ENVIRONMENT &amp; CERTIFICATION</td></tr><tr><td>SHOCK</td><td>15G, 11ms duration</td></tr><tr><td>VIBRATION</td><td>1 Grms/ 5~ 500Hz/ Operation</td></tr><tr><td>OPERATING TEMPERATURE</td><td>0&deg;C ~ 60&deg;C (32&deg;F ~ 140&deg;F)</td></tr><tr><td>STORAGE TEMPERATURE</td><td>-20&deg;C ~ 85&deg;C (-4&deg;F ~ 185&deg;F)</td></tr><tr><td>OPERATING HUMIDITY</td><td>10 ~ 90% Relative Humidity, Non-condensing</td></tr><tr><td>CERTIFICATION</td><td>CE/FCC Class A<br />LVD</td></tr><tr><td>ESG DECLARATION</td><td>EU RoHS<br />China RoHS<br />REACH</td></tr></tbody></table><p>&nbsp;</p><p>Ürünün PDF&#39;ine aşağıdaki linkten ulaşabilirsiniz,</p><p><a href="https://www.merpazar.com/files/PDF/ANIPC499.pdf" target="_blank"><img alt="" src="https://www.merpazar.com/files/PDF/pdf_logo.svg" style="height: 100px; width: 100px;" /></a></p>
