<table border="1" cellpadding="0" cellspacing="0" style="width:1234px;"><tbody><tr><td style="line-height:1.3;width:247px;"><p>Model</p></td><td colspan="2" style="line-height:1.3;width:987px;"><p>&ndash; HPC156SC-FP6412</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Main System</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; Intel&reg; Elkhart Lake J6412 2.0GHz/QC processor<br />&ndash; DDR4-3200MHz SO-DIMM up to 32GB<br />&ndash; 128MB SPI Flash ROM BIOS<br />&ndash; 2* 3W/8&Omega; speaker<br />&ndash; Watchdog Timer 256 levels, 0~255 sec.<br />&ndash; OS Support Windows 10/ 11 / Linux (Option)</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Display</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; NEMA 4 rugged protection, Full planar metal border<br />&ndash; 15.6&Prime; With LED Backlight<br />&ndash; 250nits Brightness (cd/m&sup2;)<br />&ndash; 262K display color<br />&ndash; 1920 x1080 @ 60Hz resolution<br />&ndash; 170&deg;/170&deg; viewing angle (H/V)<br />&ndash; 0. 17925 x 0.17925mm pixel pitch<br />&ndash; 16:9 aspect ratio<br />&ndash; 800:1 contrast ratio<br />&ndash; 35ms response time</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Touch Screen</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; Projected capacitive type<br />&ndash; 387.00 x 231.00mm &plusmn;0.3mm<br />&ndash; Transparency ≧85%<br />&ndash; Surface Hardness ≧6H (JIS-5400)<br />&ndash; Glass haze value ≦3%</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>I/O Connector</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; 2* USB3.2 (Gen1)<br />&ndash; 4* USB2.0<br />&ndash; 1* 8bit GPIO<br />&ndash; 2* RS232<br />&ndash; 2* RS232/422/485<br />&ndash; 1* HDMI2.0 (Max Resolution: 3840 x 2160@60Hz)<br />&ndash; 2* Intel&reg; i225-V 2.5GbE<br />&ndash; 1* Locking Jack 12~28V DC input<br />&ndash; 1* Power button</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Storage</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; 1* 2.5&rdquo; SATA bay<br />&ndash; 1* M.2 M key (2242/2280, SATA/NVMe)</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Expansion</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; 1* M.2 E-key (2230 for WIFI/BT Module)<br />&ndash; 1* M.2 B-key (3042/3052 for 4G/5G Module)</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Case</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; Aluminum panel<br />&ndash; Iron case<br />&ndash; Silver + White color<br />&ndash; Spray paint coating requirement</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Power</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; AC version: 100~240V AC-DC 60W power adapter or<br />&ndash; DC version: 12VDC with over current protection fuse<br />&ndash; Consumption: 27.5W</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Compliance</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; CE, FCC, option</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Safety</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; Shock: 15G, 11ms duration<br />&ndash; Vibration: 5~500Hz/1 Grms</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Dimensions</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; 391.0 x 239.0 x 59.7mm</p></td></tr><tr><td style="line-height:1.3;width:247px;"><p>Temperature</p></td><td colspan="3" style="line-height:1.3;width:987px;"><p>&ndash; Operating: -10&deg;C ~ 60&deg;C (with W.T. DRAM/HDD in airflow condition)<br />&ndash; Operating:-10&deg;C ~70&deg;C<br />&ndash; Storage: -20&deg;C ~70&deg;C</p></td></tr></tbody></table><p>&nbsp;</p><p>Ürünün PDF&#39;ine aşağıdaki linkten ulaşabilirsiniz,</p><p><a href="https://jetwayipc.com/plg/HPC156SC-FP6412.pdf" target="_blank"><img alt="" src="https://www.merpazar.com/files/PDF/pdf_logo.svg" style="height: 100px; width: 100px;" /></a></p>
