<table id="spec_table"><tbody><tr><td colspan="2">SYSTEM</td></tr><tr><td>MB FORM FACTOR</td><td>Others</td></tr><tr><td>CPU</td><td>Onboard Intel&reg; Celeron&reg; Processor J6412 (Formerly Elkhart Lake, TDP 10W)</td></tr><tr><td>CHIPSET</td><td>Intel&reg; SoC</td></tr><tr><td>MEMORY</td><td>1 x DDR4 3200MHz, Single Channel SO-DIMM, up to 32GB</td></tr><tr><td>BIOS</td><td>AMI Flash ROM</td></tr><tr><td>WATCHDOG TIMER</td><td>255 Levels</td></tr><tr><td>SECURITY</td><td>TPM2.0 (Optional)</td></tr><tr><td>OS SUPPORT</td><td>Windows&reg; 11 (64bit)<br />Windows&reg; 10 (64bit)<br />Linux</td></tr><tr><td colspan="2">POWER</td></tr><tr><td>POWER REQUIREMENT</td><td>DC-in 12V</td></tr><tr><td>POWER ON MODE</td><td>AT / ATX</td></tr><tr><td colspan="2">DISPLAY</td></tr><tr><td>GPU</td><td>Intel&reg; HD Graphics</td></tr><tr><td>HDMI</td><td>1 x HDMI 2.0 (Max Resolution: 4096 x 2160@60Hz)</td></tr><tr><td colspan="2">LAN</td></tr><tr><td>ETHERNET</td><td>4 x RJ45 for Intel&reg; I226-V 2.5GbE</td></tr><tr><td colspan="2">SYSTEM I/O</td></tr><tr><td>REAR PANEL I/O</td><td>4 x RJ45<br />1 x COM (RJ45 Type)<br />1 x DC-in Jack (12V)<br />1 x GND Hold<br />1 x WIFI Antenna Hole</td></tr><tr><td>FRONT PANEL I/O</td><td>1 x Power Button<br />1 x Power LED<br />1 x Reset Button<br />1 x USB 3.1<br />1 x USB 2.0<br />1 x HDMI<br />1 x WIFI Antenna Hole</td></tr><tr><td colspan="2">STORAGE</td></tr><tr><td>eMMC</td><td>Onboard 64GB eMMC 5.1 (optional)</td></tr><tr><td colspan="2">EXPANSION</td></tr><tr><td>M.2</td><td>1 x M-Key 2242 (PCIe Gen.3 x2/SATA interface) support NVME, (co-layout M.2 B-Key)<br />1 x E-Key 2230 (USB 2.0/PCIe 3.0 x1)<br />1 x B-Key 3042/3052 (USB3.1 interface) co-layout M.2 M-Key</td></tr><tr><td>SIM</td><td>1 x SIM Card Slot</td></tr><tr><td colspan="2">MECHANICAL</td></tr><tr><td>MOUNTING</td><td>Wall Mount</td></tr><tr><td>DIMENSIONS (W x D x H)</td><td>125.0 (W) x 109.2 (D) x 39.5 (H) mm</td></tr><tr><td colspan="2">ENVIRONMENT &amp; CERTIFICATION</td></tr><tr><td>SHOCK</td><td>15G, 11ms duration</td></tr><tr><td>VIBRATION</td><td>1 Grms/ 5~ 500Hz/ Operation</td></tr><tr><td>OPERATING TEMPERATURE</td><td>-20&deg;C ~ 60&deg;C (-4&deg;F ~ 140&deg;F)</td></tr><tr><td>STORAGE TEMPERATURE</td><td>-40&deg;C ~ 85&deg;C (-40&deg;F ~ 185&deg;F)</td></tr><tr><td>OPERATING HUMIDITY</td><td>10 ~ 95% @ 40&deg;C, Non-condensing</td></tr><tr><td>STORAGE HUMIDITY</td><td>0 ~ 95% Relative Humidity, Non-condensing</td></tr><tr><td>CERTIFICATION</td><td>CE/FCC Class A<br />LVD</td></tr><tr><td>ESG DECLARATION</td><td>EU RoHS<br />China RoHS<br />ErP</td></tr></tbody></table><p>Ürünümüz&nbsp;Windows 10, Windows 11, Pfsense 2.7.2, Ubuntu 24.04.3 ile test edilmiş olup sorunsuz çalışmaktadır.<br />&nbsp;</p><p>Ürünün PDF&#39;ine aşağıdaki linkten ulaşabilirsiniz,</p><p><a href="https://www.merpazar.com/files/PDF/BLGJW130.pdf" target="_blank"><img alt="" src="https://www.merpazar.com/files/PDF/pdf_logo.svg" style="height: 100px; width: 100px;" /></a></p>
